int | AddLayer (object Object, bool visible) |
| Adds a layer to the map. More...
|
|
int | AddLayerFromDatabase (string connectionString, string layerNameOrQuery, bool visible) |
| Adds a layer from spatial database accessed via GDAL/OGR drivers. More...
|
|
int | AddLayerFromFilename (string filename, tkFileOpenStrategy openStrategy, bool visible) |
| Adds layer from the specified datasource. More...
|
|
void | Clear () |
| Removes all data from the map and sets its properties to the default state. More...
|
|
void | ClearDrawing (int drawHandle) |
| Clears all drawings on the specified drawing layer, and removes the drawing layer. The drawing handle will no longer be valid. Call AxMap.NewDrawing again to create a new drawing layer to continue adding new elements. More...
|
|
void | ClearDrawingLabels (int drawHandle) |
| Clears labels on the specified drawing layer. More...
|
|
void | ClearDrawings () |
| Clears all drawings on all drawing layers, and removes all drawing layers. This method is slower than using ClearDrawing on a specific layer. Call AxMap.NewDrawing again to create a new drawing layer to continue adding new elements. More...
|
|
void | ClearExtentHistory () |
| Clears the extent history. More...
|
|
bool | DegreesToPixel (double degreesLngX, double degreesLatY, ref double pixelX, ref double pixelY) |
| Converts pixel coordinates to decimal degrees (map projection must be specified for this method to work). More...
|
|
bool | DegreesToProj (double degreesLngX, double degreesLatY, ref double projX, ref double projY) |
| Converts coordinates in decimal degrees to projected map coordinates (map projection must be specified for this method to work). More...
|
|
bool | DeserializeLayer (int layerHandle, string newVal) |
| Restores the state of the layer from the string generated by AxMap.SerializeLayer(). More...
|
|
bool | DeserializeMapState (string state, bool loadLayers, string basePath) |
| Restores map state from the string generated by AxMap.SerializeMapState. More...
|
|
void | DrawBackBuffer (int hdc, int imageWidth, int imageHeight) |
| Draws the content of the back buffer to specified device context. More...
|
|
void | DrawCircle (double x, double y, double pixelRadius, uint color, bool fill, byte alpha=255) |
| Draws a circle on the last drawing layer created by AxMap.NewDrawing More...
|
|
void | DrawCircleEx (int layerHandle, double x, double y, double pixelRadius, uint color, bool fill, byte alpha=255) |
| Draws a circle on the specified drawing layer. More...
|
|
int | DrawLabel (string text, double x, double y, double rotation) |
| Draws a label on the current drawing layer. More...
|
|
int | DrawLabelEx (int drawHandle, string text, double x, double y, double rotation) |
| Draws a label on the specified drawing layer. More...
|
|
void | DrawLine (double x1, double y1, double x2, double y2, int pixelWidth, uint color, byte alpha=255) |
| Draws a line on the last drawing layer created using AxMap.NewDrawing. More...
|
|
void | DrawLineEx (int layerHandle, double x1, double y1, double x2, double y2, int pixelWidth, uint color, byte alpha=255) |
| Draws a line on the specified drawing layer. More...
|
|
void | DrawPoint (double x, double y, int pixelSize, uint color, byte alpha=255) |
| Draws a point on the last drawing layer created by AxMap.NewDrawing. More...
|
|
void | DrawPointEx (int layerHandle, double x, double y, int pixelSize, uint color, byte alpha=255) |
| Draws a point on the specified drawing layer. More...
|
|
void | DrawPolygon (ref object xPoints, ref object yPoints, int numPoints, uint color, bool fill, byte alpha=255) |
| Draws a polygon on the last drawing layer created using AxMap.NewDrawing. More...
|
|
void | DrawPolygonEx (int layerHandle, ref object xPoints, ref object yPoints, int numPoints, uint color, bool fill, byte alpha=255) |
| Draws a polygon on the specified drawing layer. More...
|
|
void | DrawWideCircle (double x, double y, double pixelRadius, uint color, bool fill, short width, byte alpha=255) |
| Draws a circle with custom outline width on the last drawing layer created by AxMap.NewDrawing. More...
|
|
void | DrawWideCircleEx (int layerHandle, double x, double y, double radius, uint color, bool fill, short outlineWidth, byte alpha=255) |
| Draws a circle with custom outline width on the specified drawing layer. More...
|
|
void | DrawWidePolygon (ref object xPoints, ref object yPoints, int numPoints, uint color, bool fill, short width, byte alpha=255) |
| Draws a polygon with custom width of outline on the last drawing layer created using AxMap.NewDrawing. More...
|
|
void | DrawWidePolygonEx (int layerHandle, ref object xPoints, ref object yPoints, int numPoints, uint color, bool fill, short outlineWidth, byte alpha=255) |
| Draws a polygon with custom width of outline on the last drawing layer created using AxMap.NewDrawing. More...
|
|
bool | FindSnapPoint (double tolerance, double xScreen, double yScreen, ref double xFound, ref double yFound) |
| Returns coordinate of the shapefile point closest to specified point on screen. More...
|
|
double | GeodesicArea (Shape polygon) |
| Calculates area of polygon taking into account the shape of Earth. More...
|
|
double | GeodesicDistance (double projX1, double projY1, double projX2, double projY2) |
| Calculates geodesic distance between 2 points defined in map coordinate system. More...
|
|
double | GeodesicLength (Shape polyline) |
| Calculates length of polyline or perimeter of polygon taking into account the shape of Earth. More...
|
|
string | get_DrawingKey (int drawHandle) |
| Gets the drawing key which may be used by the programmer to store any string for a drawing layer with specified handle. More...
|
|
Labels | get_DrawingLabels (int drawingLayerIndex) |
| Gets labels associated with the drawing layer. More...
|
|
bool | get_DrawingLabelsVisible (int drawHandle) |
| Gets a boolean value which indicates whether labels of the drawing layer are visible. More...
|
|
string | get_ErrorMsg (int errorCode) |
| Retrieves the error message associated with the specified error code. More...
|
|
object | get_GetObject (int layerHandle) |
| Returns the layer object with the given handle. The object could be a Shapefile, Grid, or Image object. More...
|
|
Image | get_Image (int layerHandle) |
| Gets image object associated with the layer. More...
|
|
string | get_LayerDescription (int layerHandle) |
| Gets the description of the layer from the associated .mwsymb file. More...
|
|
bool | get_LayerDynamicVisibility (int layerHandle) |
| Gets the boolean value which indicates whether the layer will be displayed at all scales or only within the chosen range of scales. More...
|
|
Extents | get_layerExtents (int layerHandle) |
| Gets the layer extents More...
|
|
string | get_LayerFilename (int layerHandle) |
| Gets filename of datasource for the specified layer. More...
|
|
int | get_LayerHandle (int layerPosition) |
| Gets the handle of the layer at the given position in the map. Returns -1 if there is no layer at the specified position More...
|
|
string | get_LayerKey (int layerHandle) |
| Gets a string associated with a layer in the map. More...
|
|
Labels | get_LayerLabels (int layerHandle) |
| Returns labels associated with layer. More...
|
|
double | get_LayerMaxVisibleScale (int layerHandle) |
| Gets the maximum scale at which the layer is visible on the map. More...
|
|
int | get_LayerMaxVisibleZoom (int layerHandle) |
| Gets maximum zoom at which the layer will be displayed. More...
|
|
double | get_LayerMinVisibleScale (int layerHandle) |
| Gets the minimum scale at which the layer is visible on the map. More...
|
|
int | get_LayerMinVisibleZoom (int layerHandle) |
| Gets minimum zoom at which the layer will be displayed. More...
|
|
string | get_LayerName (int layerHandle) |
| Gets the name of the specified layer. More...
|
|
int | get_LayerPosition (int layerHandle) |
| Gets the position of the specified layer in the map. More...
|
|
bool | get_LayerSkipOnSaving (int layerHandle) |
| Gets a boolean value which indicates whether the layer will be serialized by appropriate routines. More...
|
|
bool | get_LayerVisible (int layerHandle) |
| Gets the visibility of the specified layer. More...
|
|
bool | get_LayerVisibleAtCurrentScale (int layerHandle) |
| Gets a value which indicates whether a layer is visible at current map scale. More...
|
|
OgrLayer | get_OgrLayer (int layerHandle) |
| Gets instance of OGR layer object associated with the specified layer. More...
|
|
Shapefile | get_Shapefile (int layerHandle) |
| Gets shapefile object associated with the layer. More...
|
|
bool | get_ShapeLayerDrawFill (int layerHandle) |
| Gets whether the specified layer is drawn with a fill. Only works on polygon shapefiles. More...
|
|
bool | get_ShapeLayerDrawLine (int layerHandle) |
| Gets whether the lines for the shapefile in specified layer are drawn. More...
|
|
bool | get_ShapeLayerDrawPoint (int layerHandle) |
| Gets whether the points/vertices for the shapefile in specified layer are drawn. More...
|
|
uint | get_ShapeLayerFillColor (int layerHandle) |
| Gets the fill color for the specified layer. Only works on polygon shapefiles. More...
|
|
tkFillStipple | get_ShapeLayerFillStipple (int layerHandle) |
| Gets the fill stipple for the specified layer. Only works on polygon shapefiles. More...
|
|
float | get_ShapeLayerFillTransparency (int layerHandle) |
| Gets the percentage of fill transparency for the specified layer. Only works on polygon shapefiles. More...
|
|
uint | get_ShapeLayerLineColor (int layerHandle) |
| Gets the line color for the specified layer. Only works on shapefiles. More...
|
|
tkLineStipple | get_ShapeLayerLineStipple (int layerHandle) |
| Gets the line stipple for the specified layer. Only works on shapefiles. More...
|
|
float | get_ShapeLayerLineWidth (int layerHandle) |
| Gets the line width for the specified layer. Only works on shapefiles. Suggested values for line width: 1 - 5 More...
|
|
uint | get_ShapeLayerPointColor (int layerHandle) |
| Gets the point color for the specified layer. Only works on shapefiles More...
|
|
float | get_ShapeLayerPointSize (int layerHandle) |
| Gets the line point/vertex size for the specified layer. Only works on shapefiles. More...
|
|
tkPointType | get_ShapeLayerPointType (int layerHandle) |
| Gets the line point type for the specified layer. Only works on shapefiles. More...
|
|
uint | get_ShapeLayerStippleColor (int layerHandle) |
| Gets the color of the polygon stipple for shapefile layer. More...
|
|
bool | get_ShapeLayerStippleTransparent (int layerHandle) |
| Gets a boolean value which indicates whether the background of fill stipple for polygon shapefile layer will be transparent. More...
|
|
WmsLayer | get_WmsLayer (int layerHandle) |
| Gets the WmsLayer More...
|
|
object | GetColorScheme (int layerHandle) |
| Returns a color scheme for the specified layer. More...
|
|
Extents | GetKnownExtents (tkKnownExtents extents) |
| Gets known extents. More...
|
|
int | HWnd () |
| Returns the handle of the window of map control. More...
|
|
bool | LoadLayerOptions (int layerHandle, string optionsName, ref string description) |
| Applies to the layer a set of settings from file with the specified name. More...
|
|
bool | LoadMapState (string filename, object callback) |
| Loads the state of the map from the file created by AxMap.SaveMapState method. More...
|
|
bool | LoadTilesForSnapshot (Extents extents, int width, string key) |
| Loads tiles for the specified map extents. More...
|
|
void | LockWindow (tkLockMode lockMode) |
| Locks the window so that any changes will not be displayed until it is unlocked. More...
|
|
bool | MoveLayer (int initialPosition, int targetPosition) |
| Moves a layer in the map from the initial position to a target position. More...
|
|
bool | MoveLayerBottom (int initialPosition) |
| Moves the specified layer below all other layers. More...
|
|
bool | MoveLayerDown (int initialPosition) |
| Moves the specified layer down one layer in the map. More...
|
|
bool | MoveLayerTop (int initialPosition) |
| Moves the specified layer to the top of all other layers. More...
|
|
bool | MoveLayerUp (int initialPosition) |
| Moves the specified layer up one layer in the map. More...
|
|
int | NewDrawing (tkDrawReferenceList projection) |
| Creates a new drawing layer on the map returning its handle. More...
|
|
bool | PixelToDegrees (double pixelX, double pixelY, ref double degreesLngX, ref double degreesLatY) |
| Converts coordinates in decimal degrees to pixel coordinates (map projection must be specified for this method to work). More...
|
|
void | PixelToProj (double pixelX, double pixelY, ref double projX, ref double projY) |
| Converts pixel coordinates to projected map coordinates More...
|
|
bool | ProjToDegrees (double projX, double projY, ref double degreesLngX, ref double degreesLatY) |
| Converts projected map coordinates to decimal degrees (map projection must be specified for this method to work). More...
|
|
void | ProjToPixel (double projX, double projY, ref double pixelX, ref double pixelY) |
| Converts projected map coordinates into screen pixel units More...
|
|
void | Redraw () |
| Redraws all layers in the map if the map is not locked. More...
|
|
void | Redraw2 (tkRedrawType redrawType) |
| Performs specific type of map redraw. More...
|
|
void | Redraw3 (tkRedrawType redrawType, bool reloadTiles) |
| Adveanced version of AxMap.Redraw2 More...
|
|
bool | ReloadOgrLayerFromSource (int ogrLayerHandle) |
| Performs the same operation as OgrLayer.ReloadFromSource, then compares projections with the Map, and if the settings allow, will reproject on-the-fly. More...
|
|
void | RemoveAllLayers () |
| Removes all layers from the map. More...
|
|
void | RemoveLayer (int layerHandle) |
| Removes the specified layer from the map More...
|
|
bool | RemoveLayerOptions (int layerHandle, string optionsName) |
| Removes set of options for the layer with the specified name. More...
|
|
void | RemoveLayerWithoutClosing (int layerHandle) |
| Removes layer from the map without its closing. More...
|
|
void | Resize (int width, int height) |
| Resizes the map to the given width and height. More...
|
|
void | ReSourceLayer (int layerHandle, string newSrcPath) |
| Changes the data source for the specified layer without its closing. More...
|
|
void | RestartBackgroundLoading (int ogrLayerHandle) |
| Restarts the background loading thread of dynamically loaded layers More...
|
|
bool | SaveLayerOptions (int layerHandle, string optionsName, bool overwrite, string description) |
| Saves settings of the layer to the file. More...
|
|
bool | SaveMapState (string filename, bool relativePaths, bool overwrite) |
| Saves the state of the map to the specified file. More...
|
|
string | SerializeLayer (int layerHandle) |
| Serializes the layer settings to the string. More...
|
|
string | SerializeMapState (bool relativePaths, string basePath) |
| Serializes map state to the string. More...
|
|
void | set_DrawingKey (int drawHandle, string newValue) |
| Sets the drawing key may be used by the programmer to store any string for a drawing layer with specified handle. More...
|
|
void | set_DrawingLabels (int drawingLayerIndex, Labels newValue) |
| Replaces the labels associated with the drawing layer. More...
|
|
void | set_DrawingLabelsVisible (int drawHandle, bool newValue) |
| Sets a boolean value which indicates whether labels of the drawing layer are visible. More...
|
|
void | set_Image (int layerHandle, Image newValue) |
| Replaces the image object associated with the layer. More...
|
|
void | set_LayerDescription (int layerHandle, string newValue) |
| Sets the description of the layer. More...
|
|
void | set_LayerDynamicVisibility (int layerHandle, bool newValue) |
| Sets the boolean value which indicates whether the layer will be displayed at all scales or only within the chosen range of scales. More...
|
|
void | set_LayerKey (int layerHandle, string newValue) |
| Sets a string associated with a layer in the map. More...
|
|
void | set_LayerLabels (int layerHandle, Labels newValue) |
| Sets the labels associated with the layer. More...
|
|
void | set_LayerMaxVisibleScale (int layerHandle, double newValue) |
| Sets the maximum scale at which the layer is visible on the map. More...
|
|
void | set_LayerMaxVisibleZoom (int layerHandle, int param0) |
| Sets maximum zoom at which the layer will be displayed. More...
|
|
void | set_LayerMinVisibleScale (int layerHandle, double newValue) |
| Sets the minimum scale at which the layer is visible on the map. More...
|
|
void | set_LayerMinVisibleZoom (int layerHandle, int param0) |
| Sets minimum zoom at which the layer will be displayed. More...
|
|
void | set_LayerName (int layerHandle, string newValue) |
| Sets the name of the specified layer. More...
|
|
void | set_LayerSkipOnSaving (int layerHandle, bool newValue) |
| Sets a boolean value which indicates whether the layer will be serialized by appropriate routines. More...
|
|
void | set_LayerVisible (int layerHandle, bool newValue) |
| Sets the visibility of the specified layer. More...
|
|
void | set_Shapefile (int layerHandle, Shapefile newValue) |
| Replaces the shapefile object associated with the layer. More...
|
|
void | set_ShapeLayerDrawFill (int layerHandle, bool newValue) |
| Sets whether the specified layer is drawn with a fill. Only works on polygon shapefiles. More...
|
|
void | set_ShapeLayerDrawLine (int layerHandle, bool newValue) |
| Sets whether the lines for the shapefile in specified layer are drawn. More...
|
|
void | set_ShapeLayerDrawPoint (int layerHandle, bool newValue) |
| Sets whether the points/vertices for the shapefile in specified layer are drawn. More...
|
|
void | set_ShapeLayerFillColor (int layerHandle, uint newValue) |
| Sets the fill color for the specified layer. Only works on polygon shapefiles More...
|
|
void | set_ShapeLayerFillStipple (int layerHandle, tkFillStipple newValue) |
| Sets the fill stipple for the specified layer. Only works on polygon shapefiles. More...
|
|
void | set_ShapeLayerFillTransparency (int layerHandle, float newValue) |
| Sets the percentage of fill transparency for the specified layer. Only works on polygon shapefiles. More...
|
|
void | set_ShapeLayerLineColor (int layerHandle, uint newValue) |
| Sets the line color for the specified layer. Only works on shapefiles. More...
|
|
void | set_ShapeLayerLineStipple (int layerHandle, tkLineStipple newValue) |
| Sets the line stipple for the specified layer. Only works on shapefiles. More...
|
|
void | set_ShapeLayerLineWidth (int layerHandle, float newValue) |
| Sets the line width for the specified layer. Only works on shapefiles. Suggested values for line width: 1 - 5 More...
|
|
void | set_ShapeLayerPointColor (int layerHandle, uint newValue) |
| Sets the point color for the specified layer. Only works on shapefiles. More...
|
|
void | set_ShapeLayerPointSize (int layerHandle, float newValue) |
| Sets the line point/vertex size for the specified layer. Only works on shapefiles. More...
|
|
void | set_ShapeLayerPointType (int layerHandle, tkPointType newValue) |
| Sets the line point type for the specified layer. Only works on shapefiles. More...
|
|
void | set_ShapeLayerStippleColor (int layerHandle, uint newValue) |
| Sets the color of the polygon stipple for shapefile layer. More...
|
|
void | set_ShapeLayerStippleTransparent (int layerHandle, bool newValue) |
| Sets a boolean value which indicates whether the background of fill stipple for polygon shapefile layer will be transparent. More...
|
|
void | SetDrawingLayerVisible (int layerHandle, bool visible) |
| Sets the boolean value which indicates whether the labels of the drawing layer are visible. More...
|
|
virtual bool | SetGeographicExtents (Extents pVal) |
| Sets geographic extents in decimal degrees for the map. More...
|
|
bool | SetGeographicExtents2 (double xLongitude, double yLatitude, double widthKilometers) |
| Sets geographic extents for the map. More...
|
|
bool | SetImageLayerColorScheme (int layerHandle, object colorScheme) |
| Sets the color scheme of an image layer More...
|
|
void | SetLatitudeLongitude (double latitude, double longitude) |
| Sets the Latitude and Longitude of the center of the screen in one operation More...
|
|
void | ShowToolTip (string text, int milliseconds) |
| Shows tooltip near the mouse cursor. More...
|
|
bool | StartNewBoundShape (double x, double y) |
| Allow to initiate digitizing a new shape with a starting point More...
|
|
bool | StartNewBoundShapeEx (int layerHandle) |
| Allow to initiate digitizing a new shape with a starting point More...
|
|
virtual void | Undo () |
| Reverts the last operation performed by user in interactive ShapeEditor. More...
|
|
void | ZoomIn (double percent) |
| Zooms the display in by the given factor. More...
|
|
void | ZoomOut (double percent) |
| Zooms the display out by the specified factor. More...
|
|
void | ZoomToLayer (int layerHandle) |
| Zooms the map display to the specified layer. More...
|
|
void | ZoomToMaxExtents () |
| Zooms the map to the maximum extents of all loaded layers.
More...
|
|
void | ZoomToMaxVisibleExtents () |
| Zooms the map to the maximum extents of all loaded visible layers. More...
|
|
int | ZoomToNext () |
| Zooms the map view to the next extents if there are next extents in the extents history. More...
|
|
int | ZoomToPrev () |
| Zooms the map view to the previous extents if there are previous extents in the extents history. More...
|
|
bool | ZoomToSelected (int layerHandle) |
| Zoomes map to display selected shapes of the specified shapefile. More...
|
|
void | ZoomToShape (int layerHandle, int shape) |
| Zooms the map display to the specified shape in the shapefile contained by the specified layer. More...
|
|
bool | ZoomToTileLevel (int zoom) |
| Zooms map to specified zoom level of the active tile provider (Tiles.Provider). More...
|
|
bool | ZoomToWorld () |
| Zooms to World extents (-180.0; 180.0; -90.0; 90.0) More...
|
|
|
tkCustomState | AnimationOnZooming [get, set] |
| Gets or sets a value indicating whether animation will be displayed zooming map in or out. More...
|
|
uint | BackColor [get, set] |
| Gets or sets the background color of the map. More...
|
|
uint | backColor [get, set] |
|
double | CurrentScale [get, set] |
| Gets or sets the current map scale. More...
|
|
int | CurrentZoom [get, set] |
| Gets or sets the current zoom level for the map. It corresponds to the zoom level of current tile provider. More...
|
|
tkCursorMode | CursorMode [get, set] |
| Gets or sets the cursor mode for the map. More...
|
|
tkCustomDrawingFlags | CustomDrawingFlags [get, set] |
| Set custom drawing flags More...
|
|
bool | DisableWaitCursor [get, set] |
| Gets or sets a boolean value which indicates whether a wait cursor will be displayed on map redraw. More...
|
|
int | ExtentHistory [get, set] |
| Gets or sets the number of extents to cache in the extents history More...
|
|
int | ExtentHistoryRedoCount [get] |
| Gets the number of previous extents to go to, forward in the undo list More...
|
|
int | ExtentHistoryUndoCount [get] |
| Gets the number of previous extents to go to, back in the undo list More...
|
|
double | ExtentPad [get, set] |
| Gets or sets the percentage of the view used to pad the extents of a layer when zooming to a layer or maximum extents. More...
|
|
Extents | Extents [get, set] |
| Gets or sets the extents of the map using an Extents object. More...
|
|
FileManager | FileManager [get] |
| Gets FileManager object associated with map. The object is used by AxMap.AddLayerFromFilename methods. More...
|
|
DrawingRectangle | FocusRectangle [get] |
| For selection boxes or dragging operations, updated with tkRedrawType.Minimal More...
|
|
Extents | GeographicExtents [get] |
| Gets geographic extents of the map in decimal degrees. More...
|
|
GeoProjection | GeoProjection [get, set] |
| Gets or sets projection for map. More...
|
|
object | GlobalCallback [get, set] |
| The global callback is the interface used by MapWinGIS to pass progress and error events to interested applications. More...
|
|
bool | GrabProjectionFromData [get, set] |
| Gets or sets a value indicating whether projection for will be taken from the first datasource added to it. More...
|
|
SelectionList | IdentifiedShapes [get] |
| Get the identified shapes More...
|
|
virtual Identifier | Identifier [get] |
| Gets an Identifier object which holds settings of tkCursorMode.cmIdentify tools. More...
|
|
tkCustomState | InertiaOnPanning [get, set] |
| Gets or sets a value indicating whether animation will be displayed to simulate inertia after panning operation. More...
|
|
tkLockMode | IsLocked [get, set] |
| Checks to see if the map is currently locked or not. More...
|
|
string | Key [get, set] |
| The key may be used by the programmer to store any string data associated with the object. More...
|
|
tkKnownExtents | KnownExtents [get, set] |
| Gets or sets known extents for the map. More...
|
|
int | LastErrorCode [get, set] |
| Retrieves the last error generated in the object. More...
|
|
float | Latitude [get, set] |
| Gets or sets latitude of the center of screen (in decimal degrees). More...
|
|
float | Longitude [get, set] |
| Gets or sets longitude of the center of screen (in decimal degrees). More...
|
|
tkCursor | MapCursor [get, set] |
| Gets or sets the cursor used with the map. When using tkCursor.crsrUserDefined be sure to set a AxMap.UDCursorHandle. More...
|
|
tkResizeBehavior | MapResizeBehavior [get, set] |
| Gets or sets the value which indicates how the control adjust its content after the resizing operations. More...
|
|
tkUnitsOfMeasure | MapUnits [get, set] |
| Gets or sets the units of measure for the map. More...
|
|
Extents | MaxExtents [get, set] |
| Gets or sets the extents of the map displayed by the control. More...
|
|
Measuring | Measuring [get] |
| Gets measuring object associated with map. More...
|
|
double | MouseWheelSpeed [get, set] |
| Gets or sets the speed of zooming with mouse wheel. More...
|
|
int | NumLayers [get] |
| Gets the number of layers loaded in the map. More...
|
|
double | PixelsPerDegree [get, set] |
| Gets the number of screen pixels per the decimal degree of the data. More...
|
|
tkMapProjection | Projection [get, set] |
| Sets projection of the map. It providers 2 most commonly used coordinate system/projections to be easily set from Form Designer. To set other projections initialize GeoProjection object manually and use AxMap.GeoProjection property. More...
|
|
bool | RecenterMapOnZoom [get, set] |
| Gets or sets a value indicating whether to move the mouse click point to the center of the map when using the Zoom In or Zoom Out tools. More...
|
|
bool | ReuseTileBuffer [get, set] |
| Gets or sets a value indicating whether currently rendered tile buffer should be scaled and reused during the next redraw. More...
|
|
tkScalebarUnits | ScalebarUnits [get, set] |
| Gets or sets units to be displayed for map scalebar. More...
|
|
bool | ScalebarVisible [get, set] |
| Gets or sets a value which indicate whether scalebar will be displayed on the map. More...
|
|
bool | SendMouseDown [get, set] |
| Gets or sets whether the map sends mouse down events. More...
|
|
bool | SendMouseMove [get, set] |
| Gets or sets whether the map sends mouse move events. More...
|
|
bool | SendMouseUp [get, set] |
| Gets or sets whether the map sends mouse up events. More...
|
|
bool | SendOnDrawBackBuffer [get, set] |
| Gets or sets a boolean value which indicates whether the map sends on draw back buffer events. More...
|
|
bool | SendSelectBoxDrag [get, set] |
| Gets or sets whether the map sends the SelectBoxDrag event. More...
|
|
bool | SendSelectBoxFinal [get, set] |
| Gets or sets whether the map sends the SelectBoxFinal event. More...
|
|
virtual ShapeEditor | ShapeEditor [get] |
| Gets instance of ShapeEditor class associated with map which stores data entered by interactive editing tools. More...
|
|
tkCoordinatesDisplay | ShowCoordinates [get, set] |
| Gets or sets a value indicating whether coordinates of the current mouse position will be displayed on map. More...
|
|
bool | ShowCoordinatesBackground [get, set] |
| Gets or sets a value indicating whether to display a white background behind the coordinates, for better contrast More...
|
|
tkAngleFormat | ShowCoordinatesFormat [get, set] |
| Allows to format coordinates in top right corner in degrees/minutes/seconds format; by default the former minutes format is used More...
|
|
bool | ShowRedrawTime [get, set] |
| Gets or sets a value which indicates whether the time of map redraw will be displayed on the screen. More...
|
|
bool | ShowVersionNumber [get, set] |
| Gets or sets a boolean value which indicate whether control's version number will be displayed on the screen. More...
|
|
bool | ShowZoomBar [get, set] |
| Gets or sets a value indicating whether zoom bar will be displayed on the map. More...
|
|
tkTileProvider | TileProvider [get, set] |
| Gets or sets tile provider for the map. More...
|
|
Tiles | Tiles [get, set] |
| Gets or sets the object of Tiles class associated with map. More...
|
|
bool | TrapRMouseDown [get, set] |
| Gets or sets a boolean value which can affect the displaying of the context menus in client code by the right click. More...
|
|
int | UDCursorHandle [get, set] |
| Gets or sets the user defined cursor handle. The handle is a windows cursor handle. More...
|
|
virtual UndoList | UndoList [get] |
| Gets list actions performed by user via interactive ShapeEditor. Provides undo/redo capability. More...
|
|
bool | UseAlternatePanCursor [get, set] |
| Gets or sets a value indicating whether the legacy 'hand' cursor should be used for map panning rather than the standard 'NSEW' four-point cursor. More...
|
|
bool | UseSeamlessPan [get, set] |
| Gets or sets a boolean value which indicate whether map will be redrawn in the course of panning operation. More...
|
|
string | VersionNumber [get, set] |
| Gets or sets version number of the control. More...
|
|
int | ZoomBarMaxZoom [get, set] |
| Gets or sets maximum zoom level to be used by zoom bar. More...
|
|
int | ZoomBarMinZoom [get, set] |
| Gets or sets minimum zoom level to be used by zoom bar. More...
|
|
tkZoomBarVerbosity | ZoomBarVerbosity [get, set] |
| Gets or sets the amount of information to be displayed in zoom bar tool tip. More...
|
|
tkZoomBehavior | ZoomBehavior [get, set] |
| Gets or sets zoom behaviour for the map control. More...
|
|
tkZoomBoxStyle | ZoomBoxStyle [get, set] |
| Gets or sets a style of zoom box, which is used to select a region with Zoom In tool. More...
|
|
double | ZoomPercent [get, set] |
| Gets or sets the factor by which to zoom the view of the map in or out. More...
|
|
|
_DMapEvents_AfterDrawingEventHandler | AfterDrawing |
| This event is fired after the rendering of drawing layers. Handle of device context is passed to allow the user to implement custom drawing. More...
|
|
_DMapEvents_AfterLayersEventHandler | AfterLayers |
| This event is fired after the rendering of standard layers. Handle of device context is passed to allow the user to implement custom drawing. More...
|
|
_DMapEvents_AfterShapeEditEventHandler | AfterShapeEdit |
| This event is fired after interactive editing of shape is finished (AxMap.CursorMode is set to tkCursorMode.cmEditShape). More...
|
|
_DMapEvents_BackgroundLoadingFinishedEventHandler | BackgroundLoadingFinished |
| This event is fired when background loading of data for OgrLayer finishes. More...
|
|
_DMapEvents_BackgroundLoadingStartedEventHandler | BackgroundLoadingStarted |
| This event is fired when background loading of data for OgrLayer starts. More...
|
|
_DMapEvents_BeforeDeleteShapeEventHandler | BeforeDeleteShape |
| This event is fired before shape is deleted in interactive ShapeEditor. More...
|
|
_DMapEvents_BeforeDrawingEventHandler | BeforeDrawing |
| This event is fired before the rendering of drawing layers. Handle of device context is passed to allow the user to implement custom drawing. More...
|
|
_DMapEvents_BeforeLayersEventHandler | BeforeLayers |
| This event is fired before the rendering of standard layers. Handle of device context is passed to allow the user to implement custom drawing. More...
|
|
_DMapEvents_BeforeShapeEditEventHandler | BeforeShapeEdit |
| This event is fired before editing starts for particular shape (after user click on the shape when map cursor is set to tkCursorMode.cmEditShape). More...
|
|
_DMapEvents_BeforeVertexDigitizedEventHandler | BeforeVertexDigitized |
| This event is fired after the user digitized a new point and held the ALT button. Can be used to modify the coordinates. More...
|
|
_DMapEvents_ChooseLayerEventHandler | ChooseLayer |
| The event is fired when current map tool asks for the layer to work with. More...
|
|
EventHandler | DblClick |
| The event is fired when user performs double click with left mouse button while cursor is within the map control. More...
|
|
EventHandler | ExtentsChanged |
| This event is fired when the extents of the map change. More...
|
|
_DMapEvents_FileDroppedEventHandler | FileDropped |
| This event is fired when a user drags a file and drops it on the map. More...
|
|
_DMapEvents_GridOpenedEventHandler | GridOpened |
| This event is fired after grid datasource was added to the map (AxMap.AddLayer). More...
|
|
_DMapEvents_LayerAddedEventHandler | LayerAdded |
| This event is fired when a new layer has been added to the map. More...
|
|
_DMapEvents_LayerProjectionIsEmptyEventHandler | LayerProjectionIsEmpty |
| This event is fired when a new layer has been added to the map and it has no metadata about its coordinate system and projection. More...
|
|
_DMapEvents_LayerRemovedEventHandler | LayerRemoved |
| This event is fired when a layer has been removed from map. More...
|
|
_DMapEvents_LayerReprojectedEventHandler | LayerReprojected |
| This event is fired after a layer was reprojected (its original projection was different from the map projection). More...
|
|
_DMapEvents_LayerReprojectedIncompleteEventHandler | LayerReprojectedIncomplete |
| This event is fired when a layer was not fully reprojected. It is controlled by the GlobalSettings.AllowLayersWithIncompleteReprojection property. More...
|
|
_DMapEvents_MapStateEventHandler | MapState |
| This event is fired for each layer in the map when the map state is changed. More...
|
|
_DMapEvents_MeasuringChangedEventHandler | MeasuringChanged |
| This event is fired after the user adds or removes a point from the path of Measuring tool. More...
|
|
_DMapEvents_MouseDownEventHandler | MouseDown |
| This event is fired when a user has pressed a mouse button while the cursor is inside the map control. The map property AxMap.SendMouseDown must be set to True for this event to be fired. More...
|
|
_DMapEvents_MouseMoveEventHandler | MouseMove |
| This event is fired when the mouse is moved while the cursor is inside the map control. The map property AxMap.SendMouseMove must be set to True for this event to be fired. More...
|
|
_DMapEvents_MouseUpEventHandler | MouseUp |
| This event is fired when the mouse button is released while the cursor is in the map control. The map property AxMap.SendMouseUp must be set to True for this event to be fired. More...
|
|
_DMapEvents_OnDrawBackBufferEventHandler | OnDrawBackBuffer |
| This event is fired during the rendering of map after data layers and drawing layers were rendered. The map property AxMap.SendOnDrawBackBuffer must be set to True for this event to be fired. More...
|
|
_DMapEvents_OnDrawBackBuffer2EventHandler | OnDrawBackBuffer2 |
| Special version of _DMapEvents.OnDrawBackBuffer More...
|
|
EventHandler | ProjectionChanged |
| The event is fired when projection of the map control was changed. More...
|
|
_DMapEvents_ProjectionMismatchEventHandler | ProjectionMismatch |
| This event is fired when a layer was added to the map with projection / coordinate system different from those of the map control. More...
|
|
_DMapEvents_SelectBoxDragEventHandler | SelectBoxDrag |
| This event is fired while the user is dragging a selection box in the map control. The map property AxMap.SendSelectBoxDrag must be set to True for this event to be fired. More...
|
|
_DMapEvents_SelectBoxFinalEventHandler | SelectBoxFinal |
| This event is fired when the user finishes dragging a selection box in the map control. The map property AxMap.SendSelectBoxFinal must be set to True for this event to be fired. More...
|
|
_DMapEvents_SelectionChangedEventHandler | SelectionChanged |
| This event is fired after shapes were selected with tkCursorMode.cmSelection tool. More...
|
|
_DMapEvents_ShapeHighlightedEventHandler | ShapeHighlighted |
| This event is fired when mouse cursor is being moved by user and the cursor enters or leaves neighborhood of particular shape. More...
|
|
_DMapEvents_ShapeIdentifiedEventHandler | ShapeIdentified |
| This event is fired when user click on a shape with tkCursorMode.cmIdentify tool active. More...
|
|
_DMapEvents_ShapeValidationFailedEventHandler | ShapeValidationFailed |
| This event is fired when shape being created or edited has topological errors and therefore can't be saved to the layer. More...
|
|
_DMapEvents_SnapPointFoundEventHandler | SnapPointFound |
| This event is fired after a snap point was found either by the default snapping algorithm of MapWinGIS or by a SnapPointRequested handler. Setting the snappedX and snappedY allows you to override this result (use with care!). More...
|
|
_DMapEvents_SnapPointRequestedEventHandler | SnapPointRequested |
| This event is fired whenever a snap point is requested by the map before the MapWinGIS snap algorithm was run. If the isFinal flag is set to true, the default snapping algorithm of MapWinGIS will be skipped. More...
|
|
_DMapEvents_TilesLoadedEventHandler | TilesLoaded |
| This event is fired when complete set of tiles has been loaded for the new map extents. More...
|
|
EventHandler | UndoListChanged |
| This event is fired when an operations is added or removed from undo/redo list of interactive ShapeEditor. More...
|
|
_DMapEvents_ValidateShapeEventHandler | ValidateShape |
| This event is fired before a shape which is being created or edited is about to be saved back to the layer. More...
|
|
